Showing all 62 results

Ball Valves

• BSP 2pc Ball Valve


  View




  IMAGEDIAGRAM

  BSP 2pc Ball Valve

  Stainless Grade 316

  Features

  • BSP threaded ends
  • Maximum pressure 1000PSI / 69Bar W.O.G. (Water, Oil, Gas)
  • PTFE seal maximum temperature 200°C
  • Full port
  • Lockable latch handle
  • Red handle sleeve available for hot water indication

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBV208		1/4" SBV208	6.35	316	$18.75
  	SBV210		3/8" SBV210	9.53	316	$19.85
  	SBV215		1/2" SBV215	12.7	316	$25.10
  	SBV220		3/4" SBV220	19.05	316	$42.85
  	SBV225		1" SBV225	25.4	316	$49.25
  	SBV232		1 1/4" SBV232	31.8	316	$75.95
  	SBV240		1 1/2" SBV240	38.1	316	$99.15
  	SBV250		2" SBV250	50.8	316	$168.15
  	SBV265		2 1/2" SBV265	63.5	316	$333.35
  	SBV280		3" SBV280	76.2	316	$511.75

  Quick View

• BSP 3pc Ball Valve


  View




  IMAGEDIAGRAM

  BSP 3pc Ball Valve

  Stainless Grade 316

  Features

  • BSP threaded ends
  • Maximum pressure 1000PSI / 69Bar W.O.G. (Water, Oil, Gas)
  • PTFE seal maximum temperature 250°C
  • Full port
  • Lockable latch handle
  • Red handle sleeve available for hot water indication

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBV308		1/4" SBV308	6.35	316	$36.70
  	SBV310		3/8" SBV310	9.53	316	$35.70
  	SBV315		1/2" SBV315	12.7	316	$45.15
  	SBV320		3/4" SBV320	19.05	316	$62.20
  	SBV325		1" SBV325	25.4	316	$70.25
  	SBV332		1 1/4" SBV332	31.8	316	$120.05
  	SBV340		1 1/2" SBV340	38.1	316	$168.35
  	SBV350		2" SBV350	50.8	316	$253.65
  	SBV365		2 1/2" SBV365	63.5	316	$464.30
  	SBV380		3" SBV380	76.2	316	$687.35
  	SBV3100		4" SBV3100	101.6	316	$1,270.85

  Quick View

• Socket Weld 3pc Ball Valve


  View




  IMAGEDIAGRAM

  Socket Weld 3pc Ball Valve

  Stainless Grade 316

  Features

  • Socket weld connections to suit SCH10S / SCH40S Pipe
  • Maximum pressure 1000PSI / 69Bar W.O.G. (Water, Oil, Gas)
  • PTFE seal maximum temperature 250°C
  • Full port
  • Lockable latch handle
  • Red handle sleeve available for hot water indication

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBVSW315		1/2" SBVSW315	15NB	316	$56.15
  	SBVSW320		3/4" SBVSW320	20NB	316	$78.70
  	SBVSW325		1" SBVSW325	25NB	316	$105.50
  	SBVSW332		1 1/4" SBVSW332	32NB	316	$162.20
  	SBVSW340		1 1/2" SBVSW340	40NB	316	$230.70
  	SBVSW350		2" SBVSW350	50NB	316	$340.55
  	SBVSW365		2 1/2" SBVSW365	65NB	316	$576.15
  	SBVSW380		3" SBVSW380	80NB	316	$763.75
  	SBVSW3100		101.6 SBVSW3100	100NB	316	$1,412.05

  Quick View

• BSP 3pc ISO Pad Ball Valve


  View


  BSP 3pc ISO Pad Ball Valve

  Grade 316

  Features

  • ISO Mounting Pad
  • BSP threaded ends
  • Maximum pressure 1000PSI / 69Bar W.O.G. (Water, Oil, Gas)
  • PTFE seal maximum temperature 250°C
  • Full port
  • Lockable latch handle
  • Red handle sleeve available for hot water indication

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBVISO340		1 1/2" SBVISO340	38.1	316	$249.95
  	SBVISO350		2" SBVISO350	50.8	316	$377.15
  	SBVISO365		2 1/2" SBVISO365	63.5	316	$733.00
  	SBVISO380		3" SBVISO380	76.2	316	$1,077.85
  	SBVISO3100		4" SBVISO3100	101.6	316	$2,053.05

  Quick View

• BSP L Port Ball Valve


  View




  IMAGEDIAGRAM

  BSP L Port Ball Valve

  Stainless Grade 316

  Features

  • BSP threaded ends
  • Maximum pressure 1000PSI / 69Bar W.O.G. (Water, Oil, Gas)
  • PTFE seal maximum temperature 250°C
  • Lockable latch handle
  • ISO5211 mounting pad
  • Reduced port
  • 3 way valves from 2 1/2" to 4" will differ from image shown

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBVL08		1/4" SBVL08	6.35	316	$111.95
  	SBVL10		3/8" SBVL10	9.53	316	$118.60
  	SBVL15		1/2" SBVL15	12.7	316	$123.45
  	SBVL20		3/4" SBVL20	19.05	316	$218.65
  	SBVL25		1" SBVL25	25.4	316	$250.75
  	SBVL32		1 1/4" SBVL32	31.8	316	$424.25
  	SBVL40		1 1/2" SBVL40	38.1	316	$488.40
  	SBVL50		2" SBVL50	50.8	316	$686.35
  	SBVL65		2 1/2" SBVL65	63.5	316	$1,803.25
  	SBVL80		3" SBVL80	76.2	316	$2,841.40
  	SBVL100		4" SBVL100	101.6	316	$4,451.70

  Quick View

• BSP T Port Ball Valve


  View




  IMAGEDIAGRAM

  BSP T Port Ball Valve

  Stainless Grade 316

  Features

  • BSP threaded ends
  • Maximum pressure 1000PSI / 69Bar W.O.G. (Water, Oil, Gas)
  • PTFE seal maximum temperature 250°C
  • Lockable latch handle
  • ISO5211 mounting pad
  • Reduced port
  • 3 way valves from 2 1/2" to 4" will differ from image shown

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBVT08		1/4" SBVT08	6.35	316	$111.95
  	SBVT10		3/8" SBVT10	9.53	316	$118.60
  	SBVT15		1/2" SBVT15	12.7	316	$123.60
  	SBVT20		3/4" SBVT20	19.05	316	$208.15
  	SBVT25		1" SBVT25	25.4	316	$250.75
  	SBVT32		1 1/4" SBVT32	31.8	316	$424.25
  	SBVT40		1 1/2" SBVT40	38.1	316	$488.40
  	SBVT50		2" SBVT50	50.8	316	$686.35
  	SBVT65		2 1/2" SBVT65	63.5	316	$1,803.25
  	SBVT80		3" SBVT80	76.2	316	$2,841.40
  	SBVT100		4" SBVT100	101.6	316	$4,451.70

  Quick View

• Press-Fit 3pc Ball Valves


  View




  IMAGEDIAGRAM

  Press-Fit 3pc Ball Valves

  Stainless Grade 316

  Features

  • Press-fit connections
  • Full port
  • PTFE seal maximum temperature 200°C (Maximum temperature dependent on press-fit seals)
  • Lockable latch handle
  • Red handle sleeve available for hot water indication

  VIEW DIMENSIONS

  	Code	In Stock	Metric Size Code	Grade	COST	QTY	Subtotal
  	UBV15S		15 UBV15S	316	$120.54
  	UBV22S		22 UBV22S	316	$140.48
  	UBV28S		28 UBV28S	316	$179.74
  	UBV35S		35 UBV35S	316	$234.02
  	UBV42S		42 UBV42S	316	$304.94
  	UBV54S		54 UBV54S	316	$413.76

  Quick View

• Ball Valve Replacement Handle


  View


  Ball Valve Replacement Handle

  Features

  • Lockable latch handle with blue handle sleeve
  • Fits on most 2pc and 3pc Ball Valves and various other valves

  	Code	In Stock	Inch Size Code	Metric Size Code	COST	QTY	Subtotal
  	SVH20		3/4" SVH20	19.05	$15.10
  	SVH40		1 1/2" SVH40	38.1	$35.50
  	SVH50		2" SVH50	50.8	$39.00
  	SVH100		4" SVH100	101.6	$69.70
  	SVH0615		1/4"- 1/2" SVH0615	6.35 - 12.7	$14.25
  	SVH2532		1" - 1 1/4" SVH2532	25.4 - 31.8	$20.90
  	SVH6580		2 1/2 " - 3" SVH6580	63.5 - 76.2	$52.50

  Quick View

• Red Ball Valve Handle Sleeve


  View


  Red Ball Valve Handle Sleeve

  Features

  • Red handle sleeve available for hot water indication (Sleeve only, handle not included)
  • Fits on most 2pc and 3pc Ball Valves and various other valves

  	Code	In Stock	Metric Size Code	COST	QTY	Subtotal
  	SVHR08		To suit 6.35 Ball Valves SVHR08	$2.25
  	SVHR10		To suit 9.53 Ball Valves SVHR10	$2.25
  	SVHR15		To suit 12.7 Ball Valves SVHR15	$2.60
  	SVHR20		To suit 19.05 Ball Valves SVHR20	$2.60
  	SVHR25		To suit 25.4 Ball Valves SVHR25	$3.55
  	SVHR32		To suit 31.8 Ball Valves SVHR32	$4.25
  	SVHR40		To suit 38.1 Ball Valves SVHR40	$5.35
  	SVHR50		To suit 50.8 Ball Valves SVHR50	$11.00
  	SVHR65		To suit 63.5 Ball Valves SVHR65	$16.15
  	SVHR80		To suit 76.2 Ball Valves SVHR80	$18.75
  	SVHR100		To suit 101.6 Ball Valves SVHR100	$24.60

  Quick View

• Press-Fit Valve Handle Extension


  View


  Press-Fit Valve Handle Extension

  Stainless Grade 316L

  Features

  • 70mm Handle Extension
  • Extend Press-Fit Valve handle above insulation or in hard to reach places.

  	Code	In Stock	Metric Size Code	Grade	COST	QTY	Subtotal
  	UBVHE1522		15 - 22 UBVHE1522	316	$37.80
  	UBVHE2835		28 - 35 UBVHE2835	316	$37.80
  	UBVHE4254		42 - 54 UBVHE4254	316	$37.80

  Quick View

Sanitary A Series Butterfly Valve

• Butterfly A Series Valve


  View




  IMAGEDIAGRAM

  Butterfly A Series Valve

  Stainless Grade 316

  Features

  • Butt welds to Outside Diameter tube sizes
  • Maximum pressure 145PSI / 10Bar
  • Maximum working temperature 180°C (with silicone seal)
  • Multi-position trigger handle
  • Parts are interchangeable with Keystone F250 valves

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBFVA25		1" SBFVA25	25.4 SBFVA25	316	$153.96
  	SBFVA40		1 1/2" SBFVA40	38.1 SBFVA40	316	$172.86
  	SBFVA50		2" SBFVA50	50.8 SBFVA50	316	$200.07
  	SBFVA65		2 1/2" SBFVA65	63.5 SBFVA65	316	$241.53
  	SBFVA75		3" SBFVA75	76.2 SBFVA75	316	$277.05
  	SBFVA100		4" SBFVA100	101.6 SBFVA100	316	$474.72

  Quick View

• Tri Clover Butterfly A Series Valve


  View




  IMAGEDIAGRAM

  Tri Clover Butterfly A Series Valve

  Stainless Grade 316

  Features

  • Tri Clover Ferrule connection
  • Maximum pressure 145PSI / 10Bar
  • Maximum working temperature 180°C (with silicone seal)
  • Multi-position trigger handle
  • Parts are interchangeable with Keystone F250 valves

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBFVAFER40		1 1/2" SBFVAFER40	38.1 SBFVAFER40	316	$201.16
  	SBFVAFER50		2" SBFVAFER50	50.8 SBFVAFER50	316	$241.24
  	SBFVAFER75		3" SBFVAFER75	76.2 SBFVAFER75	316	$340.74
  	SBFVAFER100		4" SBFVAFER100	101.6 SBFVAFER100	316	$552.60

  Quick View

• RJT Butterfly A Series Valve


  View




  IMAGEDIAGRAM

  RJT Butterfly A Series Valve

  Stainless Grade 316

  Features

  • RJT Male to RJT Female connection
  • Maximum pressure 145PSI / 10Bar
  • Maximum working temperature 180°C (with silicone seal)
  • Multi-position trigger handle
  • Parts are interchangeable with Keystone F250 valves

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBFVAMPWL40		1 1/2" SBFVAMPWL40	38.1 SBFVAMPWL40	316	$234.99
  	SBFVAMPWL50		2" SBFVAMPWL50	50.8 SBFVAMPWL50	316	$283.77
  	SBFVAMPWL65		2 1/2" SBFVAMPWL65	63.5 SBFVAMPWL65	316	$0.00
  	SBFVAMPWL75		3" SBFVAMPWL75	76.2 SBFVAMPWL75	316	$401.43
  	SBFVAMPWL100		4" SBFVAMPWL100	101.6 SBFVAMPWL100	316	$639.03

  Quick View

• Butterfly A Series Valve Handle


  View


  Butterfly A Series Valve Handle

  Stainless Grade 304

  Features

  • Multi-position trigger handle

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBFVHA2565		1 - 2 1/2" SBFVHA2565	25.4 - 63.5 SBFVHA2565	304	$26.97
  	SBFVHA75		3" SBFVHA75	76.2 SBFVHA75	304	$26.97
  	SBFVHA100		4" SBFVHA100	101.6 SBFVHA100	304	$26.97

  Quick View

• Butterfly A Series Valve Seal Kit


  View


  Butterfly A Series Valve Seal Kit

  Silicone

  Features

  • Maximum temperature 180°C
  • Kit includes 2x PTFE shaft bush/bearings

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBFVSA25		1" SBFVSA25	25.4 SBFVSA25	Silicone	$31.20
  	SBFVSA40		1 1/2" SBFVSA40	38.1 SBFVSA40	Silicone	$40.50
  	SBFVSA50		2" SBFVSA50	50.8 SBFVSA50	Silicone	$42.81
  	SBFVSA65		2 1/2" SBFVSA65	63.5 SBFVSA65	Silicone	$56.31
  	SBFVSA75		3" SBFVSA75	76.2 SBFVSA75	Silicone	$61.74
  	SBFVSA100		4" SBFVSA100	101.6 SBFVSA100	Silicone	$101.31

  Quick View

• Butterfly A Series Disc


  View


  Butterfly A Series Disc

  Stainless Grade 316

  Features

  • To Fit A Series Valve

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBFVDA25		1" SBFVDA25	25.4 SBFVDA25	316	$20.34
  	SBFVDA40		1 1/2" SBFVDA40	38.1 SBFVDA40	316	$23.16
  	SBFVDA50		2" SBFVDA50	50.8 SBFVDA50	316	$25.86
  	SBFVDA65		2 1/2" SBFVDA65	63.5 SBFVDA65	316	$39.90
  	SBFVDA75		3" SBFVDA75	76.2 SBFVDA75	316	$48.45
  	SBFVDA100		4" SBFVDA100	101.6 SBFVDA100	316	$73.23

  Quick View

Sanitary E Series Butterfly Valve

• Butterfly E Series Valve


  View




  IMAGEDIAGRAM

  Butterfly E Series Valve

  Stainless Grade 316

  Features

  • Butt welds to Outside Diameter tube sizes
  • Maximum pressure 145PSI / 10Bar
  • Maximum working temperature 120°C (with EPDM seal)
  • Multi-position handle
  • Stainless steel trigger handle available

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBFVE25		1" SBFVE25	25.4 SBFVE25	316	$77.01
  	SBFVE40		1 1/2" SBFVE40	38.1 SBFVE40	316	$84.81
  	SBFVE50		2" SBFVE50	50.8 SBFVE50	316	$91.59
  	SBFVE65		2 1/2" SBFVE65	63.5 SBFVE65	316	$103.50
  	SBFVE75		3" SBFVE75	76.2 SBFVE75	316	$153.06
  	SBFVE100		4" SBFVE100	101.6 SBFVE100	316	$209.01
  	SBFVE150		6" SBFVE150	152.4 SBFVE150	316	$501.63

  Quick View

• Tri Clover Butterfly E Series Valve


  View




  IMAGEDIAGRAM

  Tri Clover Butterfly E Series Valve

  Stainless Grade 316

  Features

  • Tri Clover Ferrule connections
  • Maximum pressure 145PSI / 10Bar
  • Maximum working temperature 120°C (with EPDM seal)
  • Multi-position handle
  • Stainless steel trigger handle available

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBFVEFER25		1" SBFVEFER25	25.4 SBFVEFER25	316	$101.98
  	SBFVEFER40		1 1/2" SBFVEFER40	38.1 SBFVEFER40	316	$121.44
  	SBFVEFER50		2" SBFVEFER50	50.8 SBFVEFER50	316	$143.02
  	SBFVEFER65		2 1/2" SBFVEFER65	63.5 SBFVEFER65	316	$168.48
  	SBFVEFER75		3" SBFVEFER75	76.2 SBFVEFER75	316	$228.52
  	SBFVEFER100		4" SBFVEFER100	101.6 SBFVEFER100	316	$311.92

  Quick View

• RJT Butterfly E Series Valve


  View




  IMAGEDIAGRAM

  RJT Butterfly E Series Valve

  Stainless Grade 316

  Features

  • RJT Male to RJT Female connection
  • Maximum pressure 145PSI / 10Bar
  • Maximum working temperature 120°C (with EPDM seal)
  • Multi-position handle
  • Stainless steel trigger handle available

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBFVEMPWL25		1" SBFVEMPWL25	25.4 SBFVEMPWL25	316	$119.97
  	SBFVEMPWL40		1 1/2" SBFVEMPWL40	38.1 SBFVEMPWL40	316	$146.94
  	SBFVEMPWL50		2" SBFVEMPWL50	50.8 SBFVEMPWL50	316	$175.35
  	SBFVEMPWL65		2 1/2" SBFVEMPWL65	63.5 SBFVEMPWL65	316	$206.94
  	SBFVEMPWL75		3" SBFVEMPWL75	76.2 SBFVEMPWL75	316	$270.99
  	SBFVEMPWL100		4" SBFVEMPWL100	101.6 SBFVEMPWL100	316	$373.29

  Quick View

• Butterfly E Series Valve Handle


  View


  Butterfly E Series Valve Handle

  Stainless Grade 304

  Features

  • Multi-position trigger handle

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBFVHE2540		1 - 1 1/2" SBFVHE2540	25.4 - 38.1 SBFVHE2540	304	$29.04
  	SBFVHE50100		2 - 4" SBFVHE50100	50.8 - 101.6 SBFVHE50100	304	$29.04

  Quick View

• Butterfly E Series Valve Seal


  View


  Butterfly E Series Valve Seal

  EPDM

  Features

  • Maximum temperature 120°C

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBFVSE25		1" SBFVSE25	25.4 SBFVSE25	EPDM	$16.74
  	SBFVSE40		1 1/2" SBFVSE40	38.1 SBFVSE40	EPDM	$23.40
  	SBFVSE50		2" SBFVSE50	50.8 SBFVSE50	EPDM	$26.70
  	SBFVSE65		2 1/2" SBFVSE65	63.5 SBFVSE65	EPDM	$33.45
  	SBFVSE75		3" SBFVSE75	76.2 SBFVSE75	EPDM	$40.14
  	SBFVSE100		4" SBFVSE100	101.6 SBFVSE100	EPDM	$50.13

  Quick View

• Butterfly E Series Disc


  View


  Butterfly E Series Disc

  Stainless Grade 316

  Features

  • Replacement disc for E Series Valve

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBFVDE25		1" SBFVDE25	25.4 SBFVDE25	316	$17.22
  	SBFVDE40		1 1/2" SBFVDE40	38.1 SBFVDE40	316	$19.92
  	SBFVDE50		2" SBFVDE50	50.8 SBFVDE50	316	$23.64
  	SBFVDE65		2 1/2" SBFVDE65	63.5 SBFVDE65	316	$35.52
  	SBFVDE75		3" SBFVDE75	76.2 SBFVDE75	316	$44.13
  	SBFVDE100		4" SBFVDE100	101.6 SBFVDE100	316	$67.77

  Quick View

• E Series Handle Knob


  View




  IMAGEDIAGRAM

  E Series Handle Knob

  Plastic

  Features

  • M8 Thread
  • Fits end of E Series Valve Handle

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SBFVKE2575		1" - 3" SBFVKE2575	25.4 - 76.2 SBFVKE2575	316	$6.36
  	SBFVKE100150		4" - 6" SBFVKE100150	101.6 - 152.4 SBFVKE100150	316	$6.36

  Quick View

Cast Iron Valves

• Bolt Set for Lugged Valve Table E


  View


  Bolt Set for Lugged Valve Table E

  Stainless Grade 304

  Features

  • Suits Lugged Valves with Table E Stud Pattern
  • Bolts and Spring Washers Included
  • Suits One Side of Valve. Order 2 Kits if using on both sides.
  • Bolt Lengths calculated for use with our Flat Face and Light Weight flanges

  	Code	In Stock		COST	QTY	Subtotal
  	CILBVKIT50DE			$9.12
  	CILBVKIT65DE			$9.12
  	CILBVKIT80DE			$9.12
  	CILBVKIT100E			$18.24
  	CILBVKIT125DE			$22.40
  	CILBVKIT150E			$43.92
  	CILBVKIT200E			$43.92
  	CILBVKIT250E			$65.88
  	CILBVKIT300E			$145.32

  Quick View

• ANSI150 Lugged Butterfly Valve EPDM


  View




  IMAGEDIAGRAM

  ANSI150 Lugged Butterfly Valve EPDM

  Cast Iron, Stainless Grade Disc EPDM

  Features

  • ANSI150 threaded stud pattern
  • Maximum nominal working pressure 230PSI / 16Bar
  • EPDM seal temperature rating 120°C
  • EPDM is suitable for hot water, steam, alcohols, coolants, acids and bases.
  • Lockable Lever with 10 position stainless steel notch plate

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	COST	QTY	Subtotal
  	CILBV40A150		1 1/2" CILBV40A150	38.1	$146.20
  	CILBV50A150		2" CILBV50A150	50.8	$156.70
  	CILBV65A150		2 1/2" CILBV65A150	63.5	$177.30
  	CILBV80A150		3" CILBV80A150	76.2	$189.00
  	CILBV100A150		4" CILBV100A150	101.6	$277.50
  	CILBV125A150		5" CILBV125A150	127	$331.30
  	CILBV150A150		6" CILBV150A150	152.4	$387.90
  	CILBV200A150		8" CILBV200A150	203.2	$657.40

  Quick View

• Table E Lugged Butterfly Valve EPDM


  View




  IMAGEDIAGRAM

  Table E Lugged Butterfly Valve EPDM

  Cast Iron, Stainless Grade Disc EPDM

  Features

  • Table E threaded stud pattern
  • Maximum nominal working pressure 230PSI / 16Bar
  • EPDM seal temperature rating 120°C
  • EPDM is suitable for hot water, steam, alcohols, coolants, acids and bases.
  • Lockable Lever with 10 position stainless steel notch plate.
  • 350NB and 400NB are fitted with gearbox and wheel handle.

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	COST	QTY	Subtotal
  	CILBV40DE		1 1/2" CILBV40DE	38.1	$124.30
  	CILBV50DE		2" CILBV50DE	50.8	$133.15
  	CILBV65DE		2 1/2" CILBV65DE	63.5	$155.15
  	CILBV80DE		3" CILBV80DE	76.2	$160.65
  	CILBV100E		4" CILBV100E	101.6	$235.80
  	CILBV125DE		5" CILBV125DE	127	$281.60
  	CILBV150E		6" CILBV150E	150	$329.75
  	CILBV200E		8" CILBV200E	203.2	$558.75
  	CILBV250E		10" CILBV250E	250	$847.65
  	CILBV300E		12" CILBV300E	304.8	$1,422.90
  	CILBV350DE		14" CILBV350DE	350	$1,967.85
  	CILBV400DE		16" CILBV400DE	400	$4,024.45

  Quick View

• PN10-16 Lugged Butterfly Valve EPDM


  View




  IMAGEDIAGRAM

  PN10-16 Lugged Butterfly Valve EPDM

  Cast Iron, Stainless Grade Disc EPDM

  Features

  • PN10-16 threaded stud pattern
  • Maximum nominal working pressure 230PSI / 16Bar
  • EPDM seal temperature rating 120°C
  • EPDM is suitable for hot water, steam, alcohols, coolants, acids and bases.
  • Lockable Lever with 10 position stainless steel notch plate

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	COST	QTY	Subtotal
  	CILBV40PN10-16		1 1/2" CILBV40PN10-16	38.1	$146.20
  	CILBV50PN10-16		2" CILBV50PN10-16	50.8	$156.70
  	CILBV65PN10-16		2 1/2" CILBV65PN10-16	63.5	$177.30
  	CILBV80PN10-16		3" CILBV80PN10-16	76.2	$189.00
  	CILBV100PN10-16		4" CILBV100PN10-16	101.6	$277.50
  	CILBV125PN10-16		5" CILBV125PN10-16	127	$331.30
  	CILBV150PN10-16		6" CILBV150PN10-16	152.4	$387.90
  	CILBV200PN10-16		8" CILBV200PN10-16	203.2	$657.40

  Quick View

• Table E Lugged Butterfly Valve VITON


  View




  IMAGEDIAGRAM

  Table E Lugged Butterfly Valve VITON

  Cast Iron, Stainless Grade Disc VITON

  Features

  • Table E Threaded Stud Pattern
  • Maximum Nominal Working Pressure 230PSI / 16Bar
  • VITON Seal Temperature Rating: 230°C
  • VITON Is Suitable For Higher Temperatures And Restricting Permeation Of Chemicals
  • Lockable Lever With 10 Position Stainless Steel Notch Plate

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	COST	QTY	Subtotal
  	CILBV50DE-V		2" CILBV50DE-V	50.8	$256.85
  	CILBV65DE-V		2 1/2" CILBV65DE-V	63.5	$292.05
  	CILBV80DE-V		3" CILBV80DE-V	76.2	$375.85
  	CILBV100E-V		4" CILBV100E-V	101.6	$556.90
  	CILBV150E-V		6" CILBV150E-V	150	$889.15

  Quick View

• Wafer Butterfly Valve


  View




  IMAGEDIAGRAM

  Wafer Butterfly Valve

  Cast Iron, Stainless Grade 316 Disc

  Features

  • Wafer bolt pattern, suitable for most flanges (including Table E, PN16 and Ansi150)
  • Maximum nominal working pressure 230PSI / 16Bar
  • EPDM seal temperature rating 120°C
  • EPDM is suitable for hot water, steam, alcohols, coolants, acids and bases.
  • Lockable Lever with 10 position stainless steel notch plate

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	COST	QTY	Subtotal
  	CIWBV50		2" CIWBV50	50NB	$127.10
  	CIWBV65		2 1/2" CIWBV65	65NB	$144.45
  	CIWBV80		3" CIWBV80	80NB	$160.40
  	CIWBV100		4" CIWBV100	100NB	$190.55
  	CIWBV125		5" CIWBV125	125NB	$263.70
  	CIWBV150		6" CIWBV150	150NB	$286.50
  	CIWBV200		8" CIWBV200	200NB	$555.60
  	CIWBV250		10" CIWBV250	250NB	$888.10
  	CIWBV300		12" CIWBV300	300NB	$1,241.90

  Quick View

• Isolating Regulating Valve PN16


  View




  IMAGEDIAGRAM

  Isolating Regulating Valve PN16

  Cast Iron

  Features

  • Cast Iron Isolating Regulating Valve PN16 Pattern
  • 2 Measurement Heads

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	COST	QTY	Subtotal
  	CIIRV32PN16		1 1/4" CIIRV32PN16	32NB	$227.73
  	CIIRV40PN16		1 1/2" CIIRV40PN16	40NB	$232.71
  	CIIRV50PN16		2" CIIRV50PN16	50NB	$234.57
  	CIIRV65PN16		2 1/2" CIIRV65PN16	65NB	$436.59
  	CIIRV80PN16		3" CIIRV80PN16	80NB	$617.25

  Quick View

• Wafer Double Gate Check Valve


  View




  IMAGEDIAGRAM

  Wafer Double Gate Check Valve

  Cast Iron, Stainless Grade 316 Gates

  Features

  • Flanges act as wafer either side of check valve. Suitable for all flanges (including Table E, PN16 and Ansi150).
  • Springs close the two plates automatically, acting as a tight seal. Compact structure for easy maintenance and good rigidity.
  • Maximum nominal working pressure 230PSI / 16Bar
  • EPDM seal temperature rating 120°C
  • EPDM is suitable for hot water, steam, alcohols, coolants, acids and bases.
  • Valve commonly used for drinking water, sewage, sea water and oil lines.

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	COST	QTY	Subtotal
  	CIWCV50		2" CIWCV50	50NB	$99.25
  	CIWCV65		2 1/2" CIWCV65	65NB	$121.35
  	CIWCV80		3" CIWCV80	80NB	$130.70
  	CIWCV100		4" CIWCV100	100NB	$178.60
  	CIWCV125		5" CIWCV125	125NB	$235.50
  	CIWCV150		6" CIWCV150	150NB	$318.85
  	CIWCV200		8" CIWCV200	200NB	$562.35
  	CIWCV250		10" CIWCV250	250NB	$936.65
  	CIWCV300		12" CIWCV300	300NB	$1,319.05

  Quick View

• Ductile Iron Y Strainer


  View




  IMAGEDIAGRAM

  Ductile Iron Y Strainer

  Ductile Iron, Stainless Grade 316 Screen

  Features

  • Table E stud pattern
  • Maximum nominal working pressure 230PSI / 16Bar
  • Drain Plug on Cover
  • GRAPHITE Cover Gasket
  • Mesh Size: DN40-100 2mm, DN125-150 3mm, DN200-300 5mm
  • Fusion Bonded Epoxy Coated to 300 Micron
  • Measurement C below is for the mesh

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	COST	QTY	Subtotal
  	CIYS40E		1 1/2" CIYS40E	40NB	$162.75
  	CIYS50E		2" CIYS50E	50NB	$165.85
  	CIYS65E		2 1/2" CIYS65E	65NB	$208.30
  	CIYS80E		3" CIYS80E	80NB	$139.95
  	CIYS100E		4" CIYS100E	100NB	$224.25
  	CIYS125E		5" CIYS125E	125NB	$591.15
  	CIYS150E		6" CIYS150E	150NB	$532.59
  	CIYS200E		8" CIYS200E	200NB	$759.96

  Quick View

• Cast Iron Butterfly Valve Gear Box


  View




  IMAGEDIAGRAM

  Cast Iron Butterfly Valve Gear Box

  Features

  • To suit Cast Iron Butterfly Valves

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	COST	QTY	Subtotal
  	CIBVGB100		4" CIBVGB100	DN101.6	$167.30
  	CIBVGB200		8" CIBVGB200	DN200	$264.55
  	CIBVGB350		14" CIBVGB350	DN350	$368.20
  	CIBVGB400		16" CIBVGB400	DN400	$1,392.65
  	CIBVGB4080		1 1/2" - 3" CIBVGB4080	DN40 - DN80	$174.05
  	CIBVGB125150		5" - 6" CIBVGB125150	DN100 - DN150	$174.05
  	CIBVGB250300		10" CIBVGB250300	DN250	$264.55

  Quick View

• Table E Expansion Bellow


  View




  IMAGEDIAGRAM

  Table E Expansion Bellow

  Zinc Plated Flange

  Features

  • EPDM Expansion Bellow
  • Temperature rating from -15°C to 115°C
  • Galvanised Table E Flanges

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	COST	QTY	Subtotal
  	CIRB50E		2" CIRB50E	DN50	$91.40
  	CIRB65E		2 1/2" CIRB65E	DN65	$109.60
  	CIRB80E		3" CIRB80E	DN80	$138.85
  	CIRB100E		4" CIRB100E	DN100	$143.50
  	CIRB125E		5" CIRB125E	DN125	$259.75
  	CIRB150E		6" CIRB150E	DN150	$269.10
  	CIRB200E		8" CIRB200E	DN200	$384.45

  Quick View

Knife Gate Valves

• Table E Lugged Knife Gate Valve


  View


  Table E Lugged Knife Gate Valve

  Stainless Steel 316

  Features

  • Table E threaded stud pattern
  • EPDM seal temperature rating 120°C
  • EPDM is suitable for hot water, steam, alcohols, coolants, acids and bases.

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SKGV100E		4" SKGV100E	DN100	316	$1,777.90
  	SKGV150E		6" SKGV150E	DN150	316	$3,022.25

  Quick View

Sanitary Ball Valves

• Sanitary Ball Valve


  View




  IMAGEDIAGRAM

  Sanitary Ball Valve

  Stainless Grade 316

  Features

  • Butt welds to Outside Diameter tube sizes
  • Multi-position handle
  • Maximum working temperature 120°C (with EPDM seal)

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SSBV50		2" SSBV50	50.8	316	$256.17
  	SSBV75		3" SSBV75	76.2	316	$527.19
  	SSBV100	On Its Way	4" SSBV100	101.6	316	$869.07

  Quick View

• Tri Clover Sanitary Ball Valve


  View




  IMAGEDIAGRAM

  Tri Clover Sanitary Ball Valve

  Stainless Grade 316

  Features

  • Tri Clover Ferrule connections
  • Multi-position handle
  • Maximum working temperature 120°C (with EPDM seal)

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SSBVFER50		2" SSBVFER50	50.8	316	$292.00
  	SSBVFER75		3" SSBVFER75	76.2	316	$567.30
  	SSBVFER100		4" SSBVFER100	101.6	316	$909.72

  Quick View

• RJT Sanitary Ball Valve


  View




  IMAGEDIAGRAM

  RJT Sanitary Ball Valve

  Stainless Grade 316

  Features

  • RJT Male - Female connection with hex nut
  • Multi-position handle
  • Maximum working temperature 120°C (with EPDM seal)

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SSBVMPWL50		2" SSBVMPWL50	50.8	316	$339.78
  	SSBVMPWL75		3" SSBVMPWL75	76.2	316	$652.50
  	SSBVMPWL100		4" SSBVMPWL100	101.6	316	$1,036.17

  Quick View

• Sanitary Ball Valve Seal


  View


  Sanitary Ball Valve Seal

  EPDM Seal

  Features

  • Replacement seal to suit Sanitary Ball Valve

  	Code	In Stock	Inch Size Code	Metric Size Code	COST	QTY	Subtotal
  	SSBVS50		2" SSBVS50	50.8	$135.45
  	SSBVS75		3" SSBVS75	76.2	$154.05
  	SSBVS100		4" SSBVS100	101.6	$252.10

  Quick View

Sanitary Non-Return Valve

• Sanitary Non-Return Valve Seal Kit


  View




  IMAGEDIAGRAM

  Sanitary Non-Return Valve Seal Kit

  Stainless Grade 316

  Features

  • EPDM seal (Food Grade) maximum temperature 120°C
  • Kit includes: 2 x O’rings, spring and 1 x seal for end of gate/plate.

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SNRVS25		1" SNRVS25	25.4	316	$35.35
  	SNRVS40		1 1-2" SNRVS40	38.1	316	$35.35
  	SNRVS50		2" SNRVS50	50.8	316	$35.35
  	SNRVS65		2 1/2" SNRVS65	63.5	316	$44.15
  	SNRVS75		3" SNRVS75	76.2	316	$53.00
  	SNRVS100		4" SNRVS100	101.6	316	$70.70

  Quick View

• Sanitary Non-Return Valve


  View




  IMAGEDIAGRAM

  Sanitary Non-Return Valve

  Stainless Grade 316

  Features

  • Butt welds to Outside Diameter tube sizes
  • EPDM seal (Food Grade) maximum temperature 120°C
  • Centre clamp for easy access
  • Spring actioned flow control

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SNRV25		1" SNRV25	25.4	316	$178.18
  	SNRV40		1 1/2" SNRV40	38.1	316	$205.60
  	SNRV50		2" SNRV50	50.8	316	$234.24
  	SNRV65		2 1/2" SNRV65	63.5	316	$290.32
  	SNRV75		3" SNRV75	76.2	316	$352.60
  	SNRV100		4" SNRV100	101.6	316	$499.62

  Quick View

• Tri Clover Sanitary Non-Return Valve


  View




  IMAGEDIAGRAM

  Tri Clover Sanitary Non-Return Valve

  Stainless Grade 316

  Features

  • Tri Clover Ferrule connections
  • EPDM seal (Food Grade) maximum temperature 120°C
  • Centre clamp for easy access
  • Spring actioned flow control

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SNRVFER40		1 1/2" SNRVFER40	38.1	316	$239.98
  	SNRVFER50		2" SNRVFER50	50.8	316	$280.80

  Quick View

• Inline Non Return Valve


  View




  IMAGEDIAGRAM

  Inline Non Return Valve

  Stainless Grade 316

  Features

  • Able to be clamped in centre of union for easy access
  • Maximum pressure 145PSI / 10Bar
  • Maximum working temperature 120°C (with EPDM seal)
  • Spring actioned flow control
  • Can be used with Tri Clover and RJT unions

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SINRV40		1 1/2" SINRV40	38.1	316	$261.55
  	SINRV50		2" SINRV50	50.8	316	$322.05
  	SINRV65		2 1/2" SINRV65	63.5	316	$503.95
  	SINRV75		3" SINRV75	76.2	316	$636.55
  	SINRV100		4" SINRV100	101.6	316	$723.65

  Quick View

BSP Check Valves

• 2pc Spring Check Valve


  View




  IMAGEDIAGRAM

  2pc Spring Check Valve

  Stainless Grade 316

  Features

  • BSP threaded ends
  • Maximum pressure 230PSI / 16Bar
  • No seal
  • Retaining Pin for Disc Alignment
  • Stainless steel body and disc

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SSCV215		1/2" SSCV215	12.7	316	$53.60
  	SSCV220		3/4" SSCV220	19.05	316	$56.75
  	SSCV225		1" SSCV225	25.4	316	$84.05
  	SSCV232		1 1/4" SSCV232	31.8	316	$103.55
  	SSCV240		1 1/2" SSCV240	38.1	316	$143.90
  	SSCV250		2" SSCV250	50.8	316	$256.75

  Quick View

• 3pc Spring Check Valve


  View




  IMAGEDIAGRAM

  3pc Spring Check Valve

  Stainless Grade 316

  Features

  • BSP threaded ends
  • Maximum pressure 580PSI / 40Bar
  • No seal
  • No Retaining Pin for Disc Alignment
  • Stainless steel body and disc

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SSCV308		1/4" SSCV308	6.35	316	$41.25
  	SSCV310		3/8" SSCV310	9.53	316	$47.10
  	SSCV315		1/2" SSCV315	12.7	316	$73.85
  	SSCV320		3/4" SSCV320	19.05	316	$96.70
  	SSCV325		1" SSCV325	25.4	316	$138.80
  	SSCV332		1 1/4" SSCV332	31.8	316	$217.05
  	SSCV340		1 1/2" SSCV340	38.1	316	$239.90
  	SSCV350		2" SSCV350	50.8	316	$328.80
  	SSCV380		3" SSCV380	76.2	316	$999.20
  	SSCV3100		4" SSCV3100	101.6	316	$2,305.35

  Quick View

• Swing Check Valve


  View




  IMAGEDIAGRAM

  Swing Check Valve

  Stainless Grade 316

  Features

  • BSP threaded ends
  • Maximum pressure 230PSI / 16Bar
  • No seal
  • Stainless steel body and disc

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SSWCV15		1/2" SSWCV15	12.7	316	$47.00
  	SSWCV20		3/4" SSWCV20	19.05	316	$56.15
  	SSWCV25		1" SSWCV25	25.4	316	$74.45
  	SSWCV32		1 1/4" SSWCV32	31.8	316	$112.15
  	SSWCV40		1 1/2" SSWCV40	38.1	316	$141.30
  	SSWCV50		2" SSWCV50	50.8	316	$182.10
  	SSWCV65		2 1/2" SSWCV65	63.5	316	$718.90
  	SSWCV80		3" SSWCV80	76.2	316	$844.50
  	SSWCV100		4" SSWCV100	101.6	316	$2,720.75

  Quick View

• Piston Check Valve


  View




  IMAGEDIAGRAM

  Piston Check Valve

  Stainless Grade 316

  Features

  • BSP threaded ends
  • Maximum pressure 800PSI / 55Bar
  • Maximum working Maximum working temperature 230°C
  • PTFE seal maximum temperature 250°C

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SPCV15		1/2" SPCV15	12.7	316	$79.00
  	SPCV20		3/4" SPCV20	19.05	316	$107.75
  	SPCV25		1" SPCV25	25.4	316	$127.65
  	SPCV32		1 1/4" SPCV32	31.8	316	$158.65
  	SPCV40		1 1/2" SPCV40	38.1	316	$207.10
  	SPCV50		2" SPCV50	50.8	316	$227.35

  Quick View

BSP Globe & Gate Valves

• Gate Valve


  View




  IMAGEDIAGRAM

  Gate Valve

  Stainless Grade 316

  Features

  • BSP threaded ends
  • Maximum pressure 230PSI / 16Bar
  • Stainless steel body and gate
  • Aluminium handwheel
  • No seal

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SGV15		1/2" SGV15	12.7	316	$72.05
  	SGV20		3/4" SGV20	19.05	316	$75.05
  	SGV25		1" SGV25	25.4	316	$118.10
  	SGV32		1 1/4" SGV32	31.8	316	$123.40
  	SGV40		1 1/2" SGV40	38.1	316	$164.15
  	SGV50		2" SGV50	50.8	316	$207.85
  	SGV65		2 1/2" SGV65	63.5	316	$962.80
  	SGV80		3" SGV80	76.2	316	$1,520.10

  Quick View

• Globe Valve


  View




  IMAGEDIAGRAM

  Globe Valve

  Stainless Grade 316

  Features

  • BSP threaded ends
  • Maximum pressure 230PSI / 16Bar
  • Stainless steel body and gate
  • Aluminium handwheel
  • No seal

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SGLV15		1/2" SGLV15	12.7	316	$43.35
  	SGLV20		3/4" SGLV20	19.05	316	$57.85
  	SGLV25		1" SGLV25	25.4	316	$66.10
  	SGLV32		1 1/4" SGLV32	31.8	316	$109.10
  	SGLV40		1 1/2" SGLV40	38.1	316	$146.45
  	SGLV50		2" SGLV50	50.8	316	$193.40

  Quick View

• Valve Handwheel


  View


  Valve Handwheel

  Aluminium

  Features

  • Handwheel to suit Gate and Globe Valves

  	Code	In Stock	Inch Size Code	Metric Size Code	COST	QTY	Subtotal
  	SGVH15		1/2" SGVH15	12.7	$19.60
  	SGVH20		3/4" SGVH20	19.05	$19.60
  	SGVH25		1" SGVH25	25.4	$27.70
  	SGVH32		1 1/4" SGVH32	31.8	$27.70
  	SGVH40		1 1/2" SGVH40	38.1	$44.50
  	SGVH50		2" SGVH50	50.8	$44.50
  	SGVH65		2 1/2" SGVH65	63.5	$69.30
  	SGVH80		3" SGVH80	76.2	$69.30

  Quick View

BSP Mini Ball Valves

• Male Mini Ball Valve


  View




  IMAGEDIAGRAM

  Male Mini Ball Valve

  Stainless Grade 316

  Features

  • BSP threaded ends
  • Reduced port
  • Maximum pressure 900PSI / 63Bar
  • EPDM seal maximum temperature 120°C

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SMBVMM08		1/4" SMBVMM08	6.35	316	$25.75
  	SMBVMM10		3/8" SMBVMM10	9.53	316	$25.75
  	SMBVMM15	On Its Way	1/2" SMBVMM15	12.7	316	$30.80

  Quick View

• Female Mini Ball Valve


  View




  IMAGEDIAGRAM

  Female Mini Ball Valve

  Stainless Grade 316

  Features

  • BSP threaded ends
  • Reduced port
  • Maximum pressure 900PSI / 63Bar
  • EPDM seal maximum temperature 120°C

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SMBVFF08		1/4" SMBVFF08	6.35	316	$20.75
  	SMBVFF10		3/8" SMBVFF10	9.53	316	$20.75
  	SMBVFF15		1/2" SMBVFF15	12.7	316	$22.00

  Quick View

• Male-Female Mini Ball Valve


  View




  IMAGEDIAGRAM

  Male-Female Mini Ball Valve

  Stainless Grade 316

  Features

  • BSP threaded ends
  • Reduced port
  • Maximum pressure 900PSI / 63Bar
  • EPDM seal maximum temperature 120°C

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SMBVMF08	On Its Way	1/4" SMBVMF08	6.35	316	$22.65
  	SMBVMF10		3/8" SMBVMF10	9.53	316	$22.65
  	SMBVMF15		1/2" SMBVMF15	12.7	316	$26.05

  Quick View

BSP Needle Valve

• Needle Valve


  View




  IMAGEDIAGRAM

  Needle Valve

  Stainless Grade 316

  Features

  • BSP threaded ends
  • PTFE seal maximum temperature rating 200°C
  • Maximum pressure 6000PSI / 400Bar
  • T handle operation

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SNV08		1/4" SNV08	6.35	316	$120.15
  	SNV15		1/2" SNV15	12.7	316	$160.30

  Quick View

BSP Y Strainer

• Y Strainer


  View




  IMAGEDIAGRAM

  Y Strainer

  Stainless Grade 316

  Features

  • BSP threaded ends
  • Maximum pressure 800PSI / 55Bar
  • Maximum working temperature 230°C
  • Stainless steel body and mesh
  • No seal
  • Replacement mesh filters available

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SYS15		1/2" SYS15	12.7	316	$24.45
  	SYS20		3/4" SYS20	19.05	316	$34.45
  	SYS25		1" SYS25	25.4	316	$49.75
  	SYS32		1 1/4" SYS32	31.8	316	$62.15
  	SYS40		1 1/2" SYS40	38.1	316	$93.70
  	SYS50		2" SYS50	50.8	316	$140.15

  Quick View

• Y Strainer Mesh


  View


  Y Strainer Mesh

  Stainless Grade 316

  Features

  • Replacement mesh filters for Y Strainer
  • 1,000 microns (micrometres)
  • D = 1mm
  • E = 2mm

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SYSM15		1/2" SYSM15	12.7	316	$23.50
  	SYSM20		3/4" SYSM20	19.05	316	$42.85
  	SYSM25		1" SYSM25	25.4	316	$42.85
  	SYSM32		1 1/4" SYSM32	31.8	316	$49.35
  	SYSM40		1 1/2" SYSM40	38.1	316	$59.05
  	SYSM50		2" SYSM50	50.8	316	$65.25

  Quick View

Process Valves

• Lockable Sampling Valve


  View




  IMAGEDIAGRAM

  Lockable Sampling Valve

  Stainless Grade 316

  Features

  • Butt weld connection for Outside Diameter tube

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SSVL12		1/2" SSVL12	12.7	316	$97.92

  Quick View

• Sampling Diaphragm Valve


  View




  IMAGEDIAGRAM

  Sampling Diaphragm Valve

  Stainless Grade 316

  Features

  • Butt weld connection for Outside Diameter tube
  • Also available as Tri Clover ferrule connection
  • Silicone seal maximum temperature rating 180°C

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SSV12		1/2" SSV12	12.7	316	$120.00

  Quick View

• Sampling Diaphragm Valve with Triclover


  View


  Sampling Diaphragm Valve with Triclover

  Stainless Grade 316

  Features

  • Tri Clover ferrule connection
  • Also available as butt weld connection for Outside Diameter tube
  • Silicone seal maximum temperature rating 180°C

  	Code	In Stock	Inch Size Code	Metric Size Code	COST	QTY	Subtotal
  	SSVFER12		1/2" SSVFER12	12.7	$124.92

  Quick View

• Threaded Sampling Valve


  View




  IMAGEDIAGRAM

  Threaded Sampling Valve

  Stainless Grade 316

  Features

  • BSP threaded end
  • Maximum temperature rating 120°C
  • PTFE seal maximum temperature 200°C
  • Maximum pressure 145PSI / 10Bar

  VIEW DIMENSIONS

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SSVT12		1/2" SSVT12	15NB	316	$104.76

  Quick View

• Silicon Seal to suit BSP Threaded Sampling Valve


  View


  Silicon Seal to suit BSP Threaded Sampling Valve

  PTFE

  Features

  • Silicon seal maximum temperature 180°C

  	Code	In Stock	Inch Size Code	Metric Size Code	Grade	COST	QTY	Subtotal
  	SSVTS		1/2" SSVTS	12.7	PTFE	$4.14

  Quick View

• Silicone Seal to suit Sampling Diaphragm Valve


  View


  Silicone Seal to suit Sampling Diaphragm Valve

  PTFE

  Features

  • PTFE seal maximum temperature 200°C

  	Code	In Stock	Inch Size Code	Metric Size Code	COST	QTY	Subtotal
  	SSVS		1/2" SSVS	12.7	$9.42

  Quick View
